AT371 Series Heat Ageing Test Chamber

AT371 Series Heat Ageing Test Chamber is suitable for accelerated ageing and heat resistance tests by air-oven method. It is applicable for thermoplastic rubber, plastic electrical insulation and other material. It conforms to ISO 188, GB/T 3512, etc.
  • AT371
  • Anytester
Availability:

Product Description

AT371 Series Heat Ageing Test Chamber is suitable for accelerated ageing and heat resistance tests by air-oven method. It is applicable for thermoplastic rubber, plastic electrical insulation and other material. It conforms to ISO 188, GB/T 3512, etc.


Features

★ LED display temperature, PID control

★ Can pre-set working time, automatically keep the constant temperature

★ Equipped with stainless inner wall

★ Adopted OMRON solid state relay to perform long life.

★ Working temperature can be chosen as 400℃ or 500℃, please inform before order

★ Gloss window make operator can watch the sample status easy.

★ Equipped with air inlet and air outlet for air flow in the chamber


Technical Specification

Model

AT371

lWorking chamber size(mm)

350×350×400

450×450×450

450×500×500

600×600×600

lWorking temperature range

100℃ ~ 400℃ or 500℃

Temperature resolution

0.1

Temperature fluctuation

≤±0.5

Temperature uniformity

≤±2.5

Timer

1~9999min settable

Power supply

220V 50Hz

220V 50Hz

220V 50Hz
