AT381
Anytester
Product Description
AT381 Series Two Roll Mill is used to mix, scatter and plasticize materials for color matching, quality control and research. It is suitable for masterbatch, PVC, plastic, pigment dispersion on plastics, etc.
Features
Technical Specification
Model | AT381A | AT381B | AT381C | AT381D |
Capacity | 1~3kg | |||
Roll size | Ø150×320mm or customized | |||
Temperature range | RT-250℃ | R.T | RT-250℃ | |
Temperature deviation | ±3℃ |
| ±3℃ | |
Heating time | R.T to 200℃ in 25min |
| R.T~ 200℃ in 25min | |
Heating mode | Electric | Oil |
| Electric |
Cooling mode |
|
| Water | |
Nip gap | 0.05~8mm adjustable | |||
Speed of front roll | 24rpm or 0~35RPM adjustable or customized | |||
Friction ratio | 1:1.27 or customized | |||
Power | 12KW | |||
Power supply | 3phase AC380V 50Hz, 22A | |||
Dimensions (mm) | 1000×430×1150 | |||
Weight (kg) | 650 | |||
