AT342 Din 53516 Abrasione Tester Rubber Abrasion Resistance Tester

AT342 DIN Abrasion Tester is used to determine the abrasion resistance of rubber using a rotating cylindrical drum device.

Product Description

AT342 DIN Abrasion Tester is used to determine the abrasion resistance of rubber using a rotating cylindrical drum device.

Standards

ISO 4649, 20871	BS-903	DIN53516
CNS-743	JIS-K6264

Feature

★ Small specimen, save more time;

★ Nice appearance, stainless steel weights;

★ Low noise;

★ Provided with Germany imported standard rubber and sandpaper;

★ Provided with bench drill to prepare specimen of Ф16mm diameter.

Technical Specification

Model	AT342
Load	2.5N, 5N, 10N (can be adjusted to 5N, 7.5N, 10N, 12.5N, 15N, 17.5N, 20N)
Abrasion travel	40±0.2m
Travel setting	40m or 20m, preset
Test method	Rotation/non-rotation, preset
Rotating speed of drum	40±1r/min
Drum diameter	Ф150±0.2mm
Drum length	460mm
Specimen diameter	Ф16±0.2mm
Power supply	AC220V 50Hz
Dimensions	950mm×660mm×310mm
Weight	55kg
Model	AT342
Load	2.5N, 5N, 10N (can be adjusted to 5N, 7.5N, 10N, 12.5N, 15N, 17.5N, 20N)
Abrasion travel	40±0.2m
Travel setting	40m or 20m, preset
Test method	Rotation/non-rotation, preset
Rotating speed of drum	40±1r/min
Drum diameter	Ф150±0.2mm
Drum length	460mm
Specimen diameter	Ф16±0.2mm
Power supply	AC220V 50Hz
Dimensions	950mm×660mm×310mm
Weight	55kg
