AT815B Horizontal Flammability Tester

AT815B Horizontal Flammability Tester is used to determine the comparative burn rates and burn resistance of textiles.

  • AT815B

  • Anytester

Availability:
Inquire Add to Basket

Product Description

AT815B Horizontal Flammability Tester is used to determine the comparative burn rates and burn resistance of textiles.


Standards

FZ/T 01028


Features

★ Stainless steel structure, nice and durable
★ Micro-computer control, accurate, stable and reliable
★ Adjustable ignition time according to different test requirement
★ Adjustable flame height
★ With glass observation window, convenient to observe test condition
★ Equipped with air vent on the top of machine and also temperature measuring hole
★ Fully equipped with accessories, easy to operate


Technical Specification

Model

AT815B

Timing range

0.1s~999.9s

Timing accuracy

0.1s

Distance between maker lines and sample ignition place

38mm, 138mm, 292mm

Overall dimensions

400mm×225mm×550mm

Power supply

AC220V±10%, 50Hz

Weight

19kg


Standard Configuration

No.

Item

Quantity

1.

Main machine

1set

2.

Sample holder

1pc

3.

Quality certificate

1pc

4.

User manual

1pc

5.

Packing list

1pc
