AT410 Density Gradient Column

AT410 Density Gradient Column is used for accurate density measurement of small solid polymer specimens using the column method.
  • AT410
  • Anytester
Availability:

Application

AT410 Density Gradient Column is used for accurate density measurement of small solid polymer specimens using the column method.


Standards

ISO 1183-1,   11542-2

ASTM D1505

GB/T 1033.1,   21461.2

Note: This Density Gradient Column can conform to but not limit to all the standards above, for more standards conformance, please contact us.


Features

1. Modular design, embedded structure

2.The internal material of the bath is 8mm thick high transparent resin material, good insulation effect, high transparency, nice apperance.

3. High precision control system.

4.It adopts high precision SCM control, with heating and cooling system.

5.Easy to operate, configurated with all related accessories.

6. Humanized design, high efficiency.





Technical Specification

Model

HY4930

Density   gradient column

Diameter: 50mm

Accuracy: 1mm

Range: 850mm

Temp. control   accuracy

± 0.05

Temp.   uniformity

±0.1

Working   position

3 or customized

Glass float

Diameter: ≤6.5mm

Density   accuracy: 0.001g/cm3

Bath size

Outer size: 400×450×1050mm

Capacity:   0.125m3

Power supply

AC380V, 50Hz,   0.3kw


Standard Configuration
