DRH-V Automatic Thermal Conductivity Tester (Guarded Hot Plate) is used to measure the steady-state heat transfer through flat slab specimens by using the guarded hot plate method and calculate its heat conductivity of plastic, rubber, glass, fiber plate, polystyrene board, extruded sheet, foamed concrete, hollow glass, wood board and various thermal insulation materials. The slab specimen is placed between two flat parallel isothermal hot plates. Measure the heat flux through the effective area on the specimen, the temperature difference of two surfaces of the specimen and the thickness of the specimen to calculate the thermal conductivity.
DRH-V
Anytester
Product Description
DRH-V Automatic Thermal Conductivity Tester (Guarded Hot Plate) is used to measure the steady-state heat transfer through flat slab specimens by using the guarded hot plate method and calculate its heat conductivity of plastic, rubber, glass, fiber plate, polystyrene board, extruded sheet, foamed concrete, hollow glass, wood board and various thermal insulation materials. The slab specimen is placed between two flat parallel isothermal hot plates. Measure the heat flux through the effective area on the specimen, the temperature difference of two surfaces of the specimen and the thickness of the specimen to calculate the thermal conductivity.
Standards
GB/T 10294 | ISO 8302 | ASTM C177 |
Note: For more standards, please contact us.
Feature
★ Professional test software for automatically controlling the test procedure.
★ Automatic measurement of specimen thickness and automatic pressurization, suitable to measure the thermal conductivity under different pressures.
★ Automatic data acquisition, data process, print-out of form and report and data-saving.
★ Short measurement time, accurate test result, good repeatability and high automation.
Technical Specification
Model | DRH-V |
Thermal conductivity measuring range | 0.001~3.000W/m.K |
Thermal conductivity measuring accuracy | ±2% |
Thermal conductivity repeatability | ±1% |
Surface temperature range of hot surface | Room temperature~150℃ Resolution: 0.01℃ Fluctuation: ±0.01℃ |
Surface temperature range of cool surface | 0~60℃ (-5~60℃ and -30~60℃ can be customized) Resolution: 0.01℃ Fluctuation: ±0.01℃ |
Thickness measuring range | 0~100mm Resolution: 0.001mm |
Pressure measuring range | 0~500N Resolution: 0.1N |
Specimen size | Basic configuration: 300×300×(5~80)mm Other optional sizes: 100×100×(5~80)mm 200×200×(5~80)mm 600×600×(5~80)mm |
Test time of whole procedure | 60min |
Power supply | AC220V 50Hz, single-phase, 500W |
