HY0074 Yarn Classification Tester

HY0074 Yarn Classification tester is used to check cleared and un-cleared yarn to provide classification of thick and thin places, as well as check infrequently occurring yarn defects and foreign fibers in the yarn.
  • HY0074

  • Anytester

Availability:

Product Description

HY0074 Yarn Classification tester is used to check cleared and un-cleared yarn to provide classification of thick and thin places, as well as check infrequently occurring yarn defects and foreign fibers in the yarn.

Features

★ Detecting and analyzing seldom-occurring yarn faults, and classifying yarn faults

★ Controlled by CAN-bus mode, the testing system is stable, reliable and better anti-interferential.

★ Each testing unit has the function of self-calibration.

★ Scatter diagram show the distribution of yarn faults exactly, which enables precise setting of yarn clearers.

★ It can give a fault frequency in 100Km automatically by the detecting length.

★ It can set the clearing channel, and detect the yarn length automatically.

★ With database processing, convenient to copy, analyze, display and print test date.

★ It can cut faults of specified channel, and have clearing function according to the channel.

★ Detecting yarn count (yarn count monitoring), when has trouble, it will give alarm in time.


Technical Specification

Model

HY0074

Measuring principle

Capacitance detecting

Yarn count range

4 ~ 112tex (MK15)



8 ~ 200tex (MK20)

Winding speed

300 ~ 1800m/min

Measuring heads

6~12

Classification

Classifies faults into 3 major categories and 33 grades, 23 grades are usual including short thick area 16 grades, long thick area 3 grades and long thin area 4 grades. Additional 10 grades including 4 grades are short thick area and 6 grades are short

thin area. It can optimize the production process so much better

Power supply

AC220V 50Hz 300W
