HY061Z Series Automatically Single Yarn Strength Tester

HY061Z Series Automatically Single Yarn Strength Tester is used to determine the breaking load and extension of single yarns and threads up to 6000cN or 12000cN load range depending on choice of load cell.
  • HY061Z

  • Anytester

Availability:

Product Description

HY061Z Series Automatically Single Yarn Strength Tester is used to determine the breaking load and extension of single yarns and threads up to 6000cN or 12000cN load range depending on choice of load cell.


Standards

ASTM D2256

ISO 2062

BS 1932

GB/T3916, 14344




Features

★ Automatically model, up to 20 working positions

★ Computer control, LCD display, easy to operate

★ Large speed range, 50~800mm/min settable

★ With two gauge lengths: 250mm and 500mm

★ Automatically save data while sudden electricity failure

★ A dedicated printer can be provided to printout test data

★ The machine can also be connected with computer by using professional software


Technical Specification

Model

HY061Z-30

HY061Z-60

HY061Z raw silk

Load range

3000cN

6000cN

0~999.9cN; 0~6000cN

Load cell accuracy

±0.5%

Gauge length

250mm, 500mm, or customize

Pre-tension

1~100cN

Elongation range

Max 80%

Clamp speed

500~5000mm/min

Testing times

1~400 times

Yarn density

1~999.9 tex

Power supply

Ac220V, 50Hz

Dimension

550 * 430 * 1495mm

Weight

120kg
