HY033D Digital Elmendorf Tearing Tester

HY033D Digital Elmendorf Tearing Tester is used to determine the ballistic tearing strength of textiles, paper, board and film etc.

  • HY033D

  • Anytester

Availability:

Product Description

HY033D Digital Elmendorf Tearing Tester is used to determine the ballistic tearing strength of textiles, paper, board and film etc.


Standards

ASTM D1424, 5734, 1922-03a, ASTM D689

ISO13937.1, 1974, 4674.2, 9290

DIN 53862, DIN EN 21974

BS 4253, 4468

JIS L1096

GB/T 3917.1

FZ/T 60006, FZ/T75001

TAPPI T414

NEXT 17, M&S P29


Features

★ Microcomputer control, digital display, more accurate

★ With micro-printer to print out test result

★ Several test ranges by using different weights assembly to satisfy different test requirement
★ Pneumatic clamping mode, easy to operate

★ High resolution, with self-calibration function


Technical Specification

Model

HY033D

Range

0~16N, 0~32N, 0~48N, 0~64N, 0~80N, 0~96N,
 0~112N, 0~128N

Error of display value

≤±1%

Slit length

20mm±0.2mm

Working air pressure

0.5~0.7MPa

Power supply

AC220V±10%, 50Hz

Dimensions

520mm×380mm×700mm

Weight

68kg
