Product Description
AT061F Automatically Air Permeability Tester is used to determine the resistance of fabrics (woven, knitted and nonwoven textile materials), industrial paper (air filter paper, cement bag paper, industrial filter paper), leather, plastic, and chemical products to the passage of air (air flow) under constant pre-set air pressure while firmly clamped in the test rig of selected test head.
Standards
ISO 9237, 7231, 5636 | ASTM D737 | BS5636 |
DIN 53887 | JIS L1096 | GB/T 5453, 13764 |
Note: This Automatically Air Permeability Tester can conform to but not limit to all the standards above, for more standards conformance, please contact us.
Features
★ The first successful establishment metering transfer system of permeability test based on a mass flow meter, completely solve the problem of breath quality test traceability problem, bring a substantial increase in measurement accuracy;
★ With two test method: Quick test (a single test time is less than 30 seconds, the results quickly);
Stable test (fan speed increase uniform, reach to set the pressure difference, keep the pressure for a certain time to come to the results, very suitable for some relatively small permeability sample to complete high-precision test)
★ Special designed for the large amount of test, can complete a test by just press the clamp, no need other operations, data automatically save, improve the detection efficiency;
★ Adopts new technology, high configuration, the whole shell adopts imported metal paint, beautiful appearance, stable performance, easy operation, no special maintenance in the future, low maintenance costs;
Technical Specification
AT161 Automatically Air Permeability Tester | |
Measuring range | 0.8~14000mm/s(L/m2.s) |
Resolution | 0.01mm/s |
Measuring accuracy | ≤±1% |
Sample thickness range | ≤ 8mm |
Clamping method | Pneumatic clamping, automatically start the test after press the clamp |
Suction volume adjustment | Auto dynamic adjustment by feedback data |
Sample test area | 20cm2 |
Test pressure | 1~2400Pa |
Data processing capacity | Max. 3200 |
Test unit | mm / s, cm3 / cm2 / s, L / dm2 / min, m3 / m2 / min, m3 / m2 / h, dm3 / s, cfm |
Power supply | AC220V±10%, 50Hz |
Power | 1500w |
Dimensions | 550×900×1200mm(L×W×H) |
Weight | 105kg |
Standard Configuration
No. | Item | Quantity |
1. | Main machine | 1set |
2. | Calibration board | 1set |
3. | Liner o-ring | 1set |
4. | Silent air pump | 1set |
5. | Quality certificate | 1pc |
6. | User manual | 1pc |
7. | Packing list | 1pc |
