HY4241 Falling Dart Impact Tester

HY4241 Electric Falling Dart Impact Tester is used to determine the impact resistance by free-falling dart method. It can be used for plastic films, sheets and composite films e.g. PE preservative films, wrapping films, PET sheets and other food package and heavy package, aluminum foils and aluminum plastic composite films, paper and paper board etc. It can meet the request both of method A and method B.
  • HY4241

  • Anytester

Availability:

Product Description

HY4241 Electric Falling Dart Impact Tester is used to determine the impact resistance by free-falling dart method. It can be used for plastic films, sheets and composite films e.g. PE preservative films, wrapping films, PET sheets and other food package and heavy package, aluminum foils and aluminum plastic composite films, paper and paper board etc. It can meet the request both of method A and method B.


Standards

ISO 7765

ASTM D1709

GB/T 9639

JIS K7124



Note: This Electric Falling Dart Impact Tester can conform to but not limit to all the standards above, for more standards conformance, please contact us.


Features

It consists of falling dart, elevating mechanism, dart release mechanism, working table, electric cabinet, etc.

Two test methods of A & B according to standard specifies

Pneumatic clamping, convenient and reliable


Technical Specification

Model

HY4241

Operating temperature

5~35

Missile weight

50~2000g

Dart shaft

Diameter: Ф6.5±0.1mm

Length: 115mm

Hemispherical head

Ф38±1mm, Ф50±1mm

Inside diameter of   specimen clamp

125±2 mm

Impact height

0~2000mm


Standard Configuration

No.

Item

Quantity

1.

Main machine

1 set

2.

Missile weight

1 set

3.

Cable

1 pair

4.

Packing list

1 copy

5.

User manual

1 copy

6.

Quality Certificate

1 copy
