AT051F-IV Multifunctional Pilling and Snagging Tester

AT051F-IV Multifunctional Pilling and Snagging Tester is used to determine the surface fuzzes and pilling properties of both woven and knitted materials.

  • AT051F-IV

  • Anytester

Availability:
Inquire Add to Basket

Product Description

AT051F-IV Multifunctional Pilling and Snagging Tester is used to determine the surface fuzzes and pilling properties of both woven and knitted materials.


Standards:

EN   ISO 12945-1

ASTM   D3939

BS   5811

JIS   L1076

GB/T 4802.3

M&S P18A/18B/21A

Note: For more standards, please contact us.


Features

★  Metal body, firm and never deformed.

★  Imported high quality rubber cork gasket, collapsible, easy to change quickly.

★  Imported polyurethane sample tube, durable and good stability.

★ Touch screen display, beautiful and more convenient to operate


Technical Specification

Model

AT051F-IV

Number of pilling   box

4

Rotational speed

60±1rpm

Counter range

1~999999, randomly-settable

Mounting tube

Φ31.5×140 mm

Thickness: 3.2mm

Weight: 52.25g

Shore hardness: 37.5±2

Lining rubber cork

Thickness: 3.2±0.1mm

Shore hardness:82~85

Density:917~930Kg/m3

Friction: 0.92~0.95

Power supply

AC220V±10%, 50Hz

Dimensions

780×480×880

Weight

70 Kg
