AT151 Series ICI Pilling and Snagging Tester

AT151 Moisture Management Tester (MMT) is an equipment to measure the dynamic liquid transport properties of textiles such as knitted and woven fabrics in three dimensions:
  • AT151
  • Anytester
Availability:

Product Description

AT151 Series ICI Pilling and Snagging Tester is used to determine the surface fuzzes and pilling properties of both woven and knitted materials. It complies with the requirements of EN ISO 12945-1, JIS L1076, IWS TM152 and BS 5811, etc.


Features

  Imported Specimen mounting tube and corkliner make our machine more precision and the test result is same as James Heal

Corkliner adopt demountable design, it’s easy to replace

Large touch screen control and display

Box is made up of import material, more stable and easy to change corkliner.


Technical Specification

Model

HY0511S-II

HY0511S-IV

HY0511S-VI

Number of pilling box

2

4

6

Inner dimension of pilling box

235×235×235mm

Rotational speed

60±2rmin

Counter range

199999

Mounting tube

4 pcs/box

Mounting tube size

Φ31.5×140 mm

Power supply

AC220V±10%, 50Hz

Dimensions

1200×500×500

1200×500×800

1200×500×1100

Weight

45 Kg

65 Kg

96 Kg


Standard Configuration

No.

Item

Quantity

1.

Main machine

1 set

2.

Specimen Mounting tube

4 pcs/box

3.

Specimen sample template

1 pc

4.

Packing list

1 pc

5.

Quality certificate

1 pc

6.

User manual

1pc
