Fiber Shrinkage Tester

HY0364 Fiber Shrinkage Tester used to determine the heat shrinkage of various synthetic and wool staple fibers.

Product Description

HY0364 Fiber Shrinkage Tester used to determine the heat shrinkage of various synthetic and wool staple fibers.

Standards

GB/T 6505

FZ/T 50004

Note: This Fiber Shrinkage Tester can conform to but not limit to all the standards above, for more standards conformance, please contact us.

Features

★ Easy to operate, beautiful appearance.

★ Durable, and stable heating

Technical Specification

Model	HY0364
Heat shrinkage model	180 ℃ dry hot air; 100 ℃ boiling water
Temperature range	100~190℃
Temperature accuracy	±2℃
Test method	Cluster Method
Projection objective	Focal length: f = 84.47; Relative aperture: D / f = 1; 4.6
Magnification	5X
Projection Screen Size	60×60mm
Handwheel division value	0.01mm
Measuring length	16~20mm
Dimension	370 mm 310 mm 260mm
Weight	15kg

Standard Configuration
