HY3140B
Anytester
Product Description
HY3140B Pneumatic Sample Cutter is used to cut sample rubber, plastic, leather and other material of various shapes by using different knife dies. The samples can be used for tensile test, mooney viscosity test and other various tests.
Features
★ Pneumatic operation
★ Fast to cut sample, easy and simple to operate
★ Different die can be selected
★ Widely used
★ Equipped with durable cutting pad and die
Technical Specification
HY3140B Pneumatic Sample Cutter | |
Travel | 50mm |
Pressure | The cutting pressure is 7kN when the air pressure is 0.6MPa |
Input air pressure | ≥0.5MPa |
Dimension | 340mm×220mm×500mm |
Weight | 25kg |
Standard Configuration
No. | Item | Quantity |
1 | Main machine | 1set |
2 | Dumbbell die | 1 pcs |
