HY0501D Textile Moisture Permeability Chamber

HY0501D Textile Moisture Permeability Chamber is used to measure rate of water vapor transmission for fabric, padded cotton, apparel, etc.
  • HY0501D
  • Anytester
Availability:

Product Description

HY0501D Textile Moisture Permeability Chamber is used to measure rate of water vapor transmission for fabric, padded cotton, apparel, etc.


Standards

ASTM E96

GB/T 12704

JIS L1099

BS 7209



Note: This Textile Moisture Permeability Chamber can conform to but not limit to all the standards above, for more standards conformance, please contact us.


Features

  Use 16bit Industry-grade PLC (Mitsubishi, Japan), programmable controller to control temperature, humidity and time, more excellent anti-jamming, high reliability of the data

  Apply the Controllable Silicon Step-less Adjusting Technology to adjust temperature and humidity continuously and precisely, and without over heated as the PID adjusting function

  Rectangle double-layer glass observation window prevents form coagulation of hydrosphere as there is a heater in it

  Workroom made by high quality stainless steel. Operation is easy and safe as we use the plane handle without reaction

  Humidified by ultrasonic, high accuracy

  Workroom temperature and humidity settable and digital displayed

  Test time settable and duly displayed on LED of the timer


Technical Specification

Model

HY0501D

             Textile Moisture Permeability Chamber

Pot number

8

Inner diameter of pot size

φ60mm

Temperature range

0 ~ 50

Temperature division

±0.5

Humidity range

50% ~ 95%RH

Humidity division

±5%RH

Rack rotating speed

0100rpm, adjustable

Working chamber size

500 * 380 * 800mm

Power supply

AC220V±10%, 50Hz, 1000W

Dimensions

1000 × 1000 × 1400mm

Weight

180 Kg


Standard Configuration

No.

Item

Quantity

1.

Main machine

1 set

2.

Pot (for GB or BS standard)

8 pcs

3.

Rack

1 set

4.

Packing list

1pc

5.

Quality certificate

1pc

6.

User manual

1pc
